HANGER, ENGINE, NO.2
Part number: 12282-31050
Brand: Lexus
Related parts
【11028】1102831010 BRACKET SUB-ASSY, V-BANK COVER, NO.2
【11102】1110239036 HEAD SUB-ASSY
【11102】1110239126 HEAD SUB-ASSY
【11103C】1110331020 HOUSING SUB-ASSY, CAMSHAFT, RH
【11103C】1110331021 HOUSING SUB-ASSY, CAMSHAFT, RH
【11103C】1110331022 HOUSING SUB-ASSY, CAMSHAFT, RH
【11103C】1110331031 HOUSING SUB-ASSY, CAMSHAFT, RH
【11103C】1110331032 HOUSING SUB-ASSY, CAMSHAFT, RH
【11104A】1110431020 HOUSING SUB-ASSY, CAMSHAFT, LH
【11104A】1110431021 HOUSING SUB-ASSY, CAMSHAFT, LH
【11104A】1110431022 HOUSING SUB-ASSY, CAMSHAFT, LH
【11104A】1110431042 HOUSING SUB-ASSY, CAMSHAFT, LH
【11104A】1110431043 HOUSING SUB-ASSY, CAMSHAFT, LH
【11115】1111531041 GASKET, CYLINDER HEAD
【11115】1111531051 GASKET, CYLINDER HEAD
【11116】1111631021 GASKET, CYLINDER HEAD, NO.2
【11116】1111631031 GASKET, CYLINDER HEAD, NO.2
【11122B】1112231041 BUSH, EXHAUST VALVE GUIDE
【11122B】1112331041 BUSH, EXHAUST VALVE GUIDE
【11126B】1112631030 Bush, exhaust valve guide, no.2
【11126B】1112731030 Bush, exhaust valve guide, no.2
【11131A】1113131020 SEAT, INTAKE VALVE
【11131A】1113231020 SEAT, INTAKE VALVE
【11135A】1113531040 SEAT-EXHAUST VALVE
【11135A】1113631040 SEAT-EXHAUST VALVE
【11159G】1115931010 Gasket, camshaft bearing cap oil hole, rh/lh
【11193A】1119370010 Gasket, spark plug tube, rh/lh
【11201】1120131232 COVER SUB-ASSY, CYLINDER HEAD
【11201】1120131241 COVER SUB-ASSY, CYLINDER HEAD
【11201】1120131242 COVER SUB-ASSY
【11202】1120231022 COVER SUB-ASSY, CYLINDER HEAD, LH
【11209】1120931210 COVER SUB-ASSY
【11213】1121331040 GASKET, CYLINDER
【11213】1121331050 GASKET, CYLINDER
【11214】1121431020 Gasket, cylinder head cover, no.2
【11254】1125431020 Bracket, v-bank
【12108】1218021010 CAP SUB-ASSY, OIL FILLER
【15340】1533031020 VALVE ASSY, CAM TIMING OIL CONTROL, RH
【15340】1533038010 Valve assy, cam timing oil control, rh/lh
【15340】1534031020 Valve assy, cam timing oil control, rh/lh
【15678E】1567846020 FILTER, OIL CONTROL VALVE
【15340A】9009914137 O-RING
【11254B】9010906385 CLAMP OR CLIP(FOR FUEL HOSE NO.1)
【11153A】9011907009 BOLT(FOR CAMSHAFT BEARING CAP TO HOUSING, NO.1),RH/LH
【11119A】9025005021 Direct marketing no.1
【11155A】9025311021 CLAMP OR CLIP(FOR FUEL HOSE NO.1)
【11117K】9034120012 PLUG, W/HEAD STRAIGHT SCREW(FOR OIL FILTER BRACKET)
【11117L】9034127006 Plug no.2 (for oil pan)
【11117M】9043020004 Gasket (for coolant hole no.2)
【11117N】9043027005 Gasket no.2
【12108A】9043037140 GASKET(FOR OIL FILLER CAP)
