BRACKET,FRT BPR FASCIA OTR

【39】11513599 NUT,U-TYPE,M4.2X1.41,0.65-3.80 PNL THK,PZ(HTR & A/C CONT)(ACDelco #11513599)

【5】11514517 NUT,HEX,W/CON SPR WA,M6X1,5.7THK,18 O.D.,9,7111M(O/S RR VIEW MIR OPG APLQ)

【23】11516594 Bolt, brake pedal bracket (M8X1.25X30) (8.900)

【15】11518908 Nut (2.726), upper

【31】11519376 BOLT - LWR ARM

【22】11569917 NUT,F/END UPR TIE BAR(M8X1.25X17)(3.015)

【13】11570136 Bolt, hexagon head w/conical spring M6X1X23, threaded 14, o/d 17,8, GMW3359 (instrument panel center

【41】11570498 BOLT, HX HD W/FLAT

【16】11589015 BOLT,HWH W/FL WA M4.2X1.41X20,12.5 O.D.,DOG PT,6010M,7253M(STRG COL WRG HARN CON

【34】11589289 Set, push-in, with 6.5 hole, plate thickness 2-4.5, nylon 6/6 PER GMP. PA66.0 (ambient gauge sensor

【3】11609341 Bolt, rear door lock (M6X1.0X16 mm) (length 22.85)

【27】11609982 Bolt, hexagon w/washer, M6X1X22, threaded 14.55, o/d 24, 8.8, GMW3359, M-PT (oil cooler carrier)

【7】11609989 BOLT,HEX W/FLAT WASHER,M6X1X25,15 THD,17 OD,6202M STL,GMW3200,TAPTITE(COOL RCVY

【8】11610157 NUT,PNL,M4.2X1.41,8.5X11.9,2.3-2.8 PNL,FITS 11.2X9.2 HOLE,1050,GMW33(PART OF 1)(

【17】11611465 Bolt, stud (39,68 of the parts) (2.210)

【12】22790919 GUIDE,FRT BPR FASCIA

【29】23135212 DEFLECTOR,F/CMPT AIR

【6】23213880 SUPPORT,FRT BPR FASCIA CTR

【18】23369005 ABSORBER,FRT BPR FASCIA ENGY

【38】23507622 GRILLE,FRT LWR(INCLS 2,5,6)(CARBON FLASH MET)
