Tube (incl 280) (* package 4)

【214】11518792 Retainer, c

【210】11519038 Bolt, oil pan (part of 1) (M6X1X30) (0.724)

【272】11519970 Bolt, camshaft cover (M6X1.0X40) (8.900)

【201】11547931 Bolt (46,49 parts), pcv valve

【265】11561583 Plug-timing chain hood

【253】11562426 Bolt (26 parts) (M6X30) (3.901)

【238】11588547 Plug, M12X1.75 (plug type) (* package 2) (8.973)

【213】11588715 Bolt, water pump (11 parts) (M6X1.0X35 mm)

【209】11588719 Bolt/screw-crankcase lower

【262】11588724 Bolt-oil pump sprocket

【237】11610687 Bolt, cylinder head (M11X2X165 mm)

【273】11611354 Bolt, camshaft bearing cap (ex part) (M6X1X85 mm)

【224】11611823 Bolt (5 parts) of camshaft bearing cap (M6X1X43.4MM)

【247】12565836 Seal, valve (intake side) (* package 1, package 5)

【254】12570326 Pin, cylinder head dowel

【268】12574477 CAMSHAFT

【245】12575196 Set, valve spring (215 of the parts)

【244】12575197 Plate, valve lock (f 215)

【241】12613249 Seal (216 parts)

【250】12626252 Seal (O-ring), camshaft position sensor (service: replace parts if loose or removed) (part of 34) (t

【222】12626896 Camshaft, intake (incl. 268)

【263】12626916 Bracket-engine lifting fr

【228】12626917 Bracket, engine lifting, rear

【220】12627105 Shim (216 parts), inner (circular)

【271】12627184 RAIL, GUIDE TIMEN CHANIN

【255】12629404 GASKET, CYLINDER HEAD

【276】12634516 Gasket, intake camshaft cover (216 parts)

【274】12634517 Gasket, exhaust camshaft cover (216 parts)

【221】12635744 Gasket (for 216 parts), camshaft hood inner (figure 8)

【275】12635953 Gasket, cam shf cover (216 parts) (irregular rectangular gasket)

【251】12638266 Sensor, camshaft position (incl. 250,252,253)

【277】12642334 Seal, pcv valve (13.94 id o-ring) (54 off)

【264】12646961 Plug, cylinder head oil gallery (256 parts) (cup-shaped, 10.5 outer diameter, 5,304 thick stainless

【247】12653350 Seal, valve (exhaust side) (* package 1)

【257】12653994 Valve (12653994*12684736), exh

【281】12654076 Tube, pcv (cam cap to turbo)

【239】12654646 ROCKER-VALVE

【231】12655276 INTAKE MANIFOLD GASKET

【266】12656389 Pin, camshaft bearing cap

【242】12656486 ROCKER-VALVE

【232】12657167 Gasket, exhaust manifold

【258】12662527 Valve, intake (* package 1)

【200】12662736 Solenoid, camshaft actuator intake (incl. 218,219)

【217】12662737 Solenoid, exhaust camshaft position actuator (incl. 218,219)

【208】12663027 Valve, pcv (turbo block) (incl. 53 x [35] (turbo vacuum)

【206】12665166 Valve, pcv (incl 201, 202, 207) (part of 216) (auxiliary)

【203】12665167 Valve, pcv (incl 201, 202, 204) (216 of the parts) (fresh air)

【212】12668429 Oil seal, eng vacuum pump

【243】12681659 Plug, gasoline ignition

【257】12684736 Valve (12653994*12684736), exh

【216】12686425 Cover (incl 12655189) (50L/min pcv) (incl 203,205,206,208-212,220,221,241,267,274-276,

【246】12686721 Spring, valve (* package 1)

【249】12686787 Tappet assy-valve

【249】12686789 Tappet assy-valve

【249】12686790 Adjuster, hydraulic valve (12686787*12686789*12686790)

【216】25201395 Cover (incl. 55596783) (30L/min pcv) (incl. 203,205,206,208-212,220,221,241,267,272,273,

【215】25202791 Coil, ignition (incl. 213,214)

【227】25203252 Camshaft, exhaust (incl. 268)

【267】3525915 Dowel pin

【278】55596783 Valve, pcv (incl 277x16 parts) (main) (30L/min pcv)

【280】90765173 Bolt, telephone control module (2.812)

【230】93733279 Grommet (60 parts) (10 ML) (medium strength thread locking agent to prevent loosening) (8.800)

【233】93737600 Sealant, pcv (150g) (8.800)

【282】94040323 Gasket, cam shf cover (216 parts)
