Courtesy lamp assy.

【005】11570498 BOLT, HX HD W/FLAT

【011】11589289 Set, push-in, with 6.5 hole, plate thickness 2-4.5, nylon 6/6 PER GMP. PA66.0 (ambient gauge sensor

【009】11589291 Clamp, eng harness (press) (black) (34.8) (6 )

【005】11609465 Bolt, HWH, M4.2X1.41X18, 12.5 od, 6010 M, PS (for parts of 1) (8.977)

【006】11611523 Nut (U) (push) (insert 8.75 hole) (nut) (9.675)

【014】13252118 Retainer, front side door garnish (part 1) (blue) (M7.4X13MM) (male tape color) (14.760)

【001】26264037 Trim (incl 10), tailgat

【010】26281234 Clip, tailgate garnish

【004】26281237 Panel, tailgate lower garnish (incl 13)

【002】26303580 Panel, tailgate lower garnish (incl 13)

【001】26303585 Panel, tailgate garnish (incl, 10,12)

【003】26303586 Panel, tailgate lower garnish (incl 15)

【011】26327164 Retainer, tailgate

【007】26363117 Courtesy lamp assy.

【007】26671171 Courtesy lamp assy.

【007】26671172 Courtesy lamp assy.

【001】26679577 Trim (incl. 8,10), rh/lh

【001】9006563 Trim (incl 10), tailgat

【004】9006565 Trim assy-tailgate lower

【002】9006571 Trim assy-tailgate lower

【003】9006572 Trim assy-tailgate lower

【011】9006578 Set, lift door trim

【008】9006579 Cover, lift door lock striker
