HOSERADINA

【061】11548002 Bolt, injector feed tube (1.652)

【056】11548165 Bolt, crankshaft position sensor (maximum length: 28.4) (1.762)

【039】11548323 Clamp, thermostat by-pass hose (63 parts) (19X12MM)

【044】11548784 Clip (40 parts)

【065】11549028 Bolt, turbo stud

【012】11549305 Clip (10 parts) water pump outlet hose

【064】11610137 Bolt, stud (3.162)

【059】11611503 Clamp (27 parts)

【062】12683379 Gasket (3.358), turboc

【013】13162312 Clip (42mm), radiator mouth hose

【046】13162322 Clip (40 parts) (black) (38X12MM) (1.166)

【007】13502353 CAP, RAD SURGE TK

【022】24113005 Bolt, eng coolant thermostat housing (3.671)

【063】24113410 Hose, engine oil cooler coolant outlet (china) (including 30-39)

【063】24117265 Hose, engine oil cooler coolant outlet (china) (including 30-39)

【016】26234301 HOSE RAD IN

【019】26234302 HOSE RAD OUT

【004】26305025 Hose, radiator reserve tank inlet

【017】26319146 Connector-w/cvr inlet hose

【016】26332559 HOSE RAD IN

【009】26332592 Radiator reserve tank

【005】26332595 Hose, radiator reserve tank inlet (incl. 3,4)

【019】26396100 HOSERADOUT

【057】55488246 Sensor assy-eng coolant temp

【021】55500467 Hose, eng oil cooler coolant inlet (incl 24-29)

【038】55501077 Hose, eng oil cooler coolant outlet

【031】55501078 Connector assy

【037】55501080 Connector assy

【024】55501081 Hose, eng oil cooler coolant inlet

【027】55501082 Connector assy-eng oil cooler

【028】55501083 Hose, engine cooling air discharge

【041】55501112 Hose, engine coolant feed

【042】55501114 Hose, thermostat by-pass (for in.40)

【047】55502982 Gasket, water inlet

【048】55502983 Gasket, engine coolant manifold

【055】55506876 Exhaust pipe (for chinese engines only-transverse except E2LB) (incl. 57-60)

【058】55507951 Hose, engine coolant supply (in. 55)

【010】55507983 Pipe, engine coolant thermostat case inlet (for chinese engines only-transverse) (incl. 11-13)

【011】55507986 Hose, engine coolant bleeder

【049】55509226 Pipe, engine coolant (for china engines-transverse & O1XX only) (including 50,51xx)

【040】55509227 Hose, thermostat by-pass (for china transverse engine only) (including 41-46)

【042】55512919 Hose, thermostat by-pass (for in.40)

【040】55512920 Hose, thermostat by-pass (for china transverse engine only) (including 41-46)

【008】9030395 Bolt, ex. insulator (8.153)

【033】90572590 Clip (23mm), radiator reserve hose

【014】90765173 Bolt, telephone control module (2.812)

【015】9985406 Lubricant, pcv 3 parts
