Spacer, radiator (45 hardness), lower

【025】11507067 Nut (M6X1.0) (6 ), radiator mounting plate

【026】11546395 Nut, radiator (RPR) (20MM lh for ECF) (part of 1) (M6X20X26MM) (3.373)

【009】11602064 Bolt, a/c condenser stud

【001】11609540 Bolt (M9) (M6X1X20) (6 )

【004】11611226 Bolt, radiator (M5X1.8X20 mm) (10.240)

【003】12694431 Sensor assy-turbo

【032】23336317 Clamp, engine cooling fan shroud

【023】23444086 Cock assy-radiator drain

【027】42808694 Radiator, (incl. 17-19,23, 26)

【019】55497116 Sensor, eng coolant temperature

【018】55555982 Sensor assy-coolant temperature

【028】84194959 Motor (l-fan w/blade)

【029】84194960 Motor (rh-fan w/motor) (rh)

【016】84195288 Bracket, radiator (upper mounting pin) (upper mounting pin) (without spacer)

【021】84195289 Bracket, radiator (lower mounting pin)

【005】84195290 Deflector, radiator air side

【010】84195291 Deflector, radiator air side

【015】84256178 Seal, radiator air (CRFM top fender)

【030】84497546 Shroud-eng cooling fan

【033】84574265 Harness, eng cooling fan

【008】84574735 Condenser, air conditioner (incl 6,7,9,11,14)

【002】85525380 Intercooler assy
