Plate, radiator, lower (inc.27)

【008】11507067 Nut (M6X1.0) (6 ), radiator mounting plate

【007】11519383 Bolt, a/c evaporator tube (M6X1.0X23MM) (washer diameter 16.8) (8.900)

【002】11519506 Bolt M6X1.0X30

【030】11546395 Nut, radiator (RPR) (20MM lh for ECF) (part of 1) (M6X20X26MM) (3.373)

【019】11547421 Bolt (non-tapping bolt) (1.272)

【027】11548579 Nut, exhaust tail pipe insulator (1.269)

【020】11548673 Radiator air lwr

【003】11602064 Bolt, a/c condenser stud

【004】11611523 Nut (U) (push) (insert 8.75 hole) (nut) (9.675)

【025】1605396 Packing, hood side (black) (M7.62X20.31 mm) (8.950)

【021】23194933 Plate, radiator, upper (incl. 26)

【016】23242469 Seal, radiator air side

【024】23306427 Deflector

【006】23419654 Fan, eng cooling

【022】23450459 Deflector-air, upper

【029】23507261 Radiator, auxiliary (incl 28)

【028】25186240 Sensor, eng coolant temperature (part of 11) (with 1 seal)

【010】84110133 Insulator, radiator lower

【009】84152459 Radiator, (including 5)

【001】84172434 Bracket, radiator

【001】84172435 Bracket, radiator

【013】84394795 Cooler, transmission oil assist (incl 14)

【012】84394796 Condenser, air conditioner (incl. 3,15)

【015】84473270 Kit, receiver a/c dryer repair (incl. 11-14)
