CORE,AUX HTR(ACDelco #84406079)

【14】11562120 Bolt, stud (fr unit) M6X1X25

【4】11562121 Bolt, heater & a/c evaporator & blower module (parts of 51) (M4X1.79X16) (9.215)

【10】11562123 Bolt (front & auxiliary unit) (36,41 parts) (pan, M5X35, 8.8 steel)

【31】11569859 Bolt (36,41 parts) (M8X1.25X10)

【31】11609953 Bolt, a/c evaporator thermo expansion valve stud (parts of 36,41) (M8X1.25X11.5, M8X1.25X24, 46 TL,

【17】13579648 SEAL,A/C CMPR & CNDSR HOSE(19MM OD X 11MM ID)(PART OF 10)(SLIMLINE WASHER,1/2)(

【12】15189481 Valve, a/c evaporator & blower module drain (AC-DELCO #15-5420)

【11】15232211 Caseassy, a/c evaporator & blower, lower

【5】15798229 Actuator, module (AC-DELCO #15-73435)

【16】15798231 Seal (o-ring), heater inlet pipe

【18】15892072 Base, a/c evap in pipe bracket

【19】15920866 Thermo-valve (AC-DELCO #15-50766)

【22】15920868 Caseassy-a/c a/c evaporator & blower

【1】15920869 Case (rr), a/c evaporator & blower

【8】23169583 Pipe, heater core (import) (AC-DELCO #23169583)

【30】23169584 Pipe, heater core (AC-DELCO #23169584)

【9】25994366 Valve, auxiliary a/c evaporator thermal expansion (AC-DELCO #15-51146)

【24】84178783 MODULE,BLO MOT CONT(INCLS 24)(9.277)(ACDelco #15-81931)

【7】89019245 Grommet, a/c a/d (l) 23.5, 15.5 in d (l) (AC-DELCO #15-5/8)
